Eastland AAC Acoustic Panel
Eastland
Description
EASTLAND AAC acoustic Panels (sound insulation panels) are a type of autoclaved aerated concrete panel, reinforced with double-layer steel bars, offering excellent sound insulation and structural performance. These panels are typically used on both sides of highways (freeways) and tunnels, at railway stations and subway stations, as well as in equipment workshops or factories requiring specialized sound insulation.
EASTLAND AAC acoustics panels have passed rigorous ISO international standard tests for sound insulation and impact resistance in several countries, giving them broad application prospects.
EASTLAND AAC sound insulation panels can also be used in combination with glass wool or rock wool to enhance the sound insulation effect of the wall. EASTLAND can design, customize, and deliver sound insulation panels according to the specific needs of customers.
Sizes of Eastland AAC Acoustic Panel
Product | Code | Sizes of Products | ||
Length (mm) | Height/Width (mm) | Thickness (mm) | ||
EASTLAND AAC Acoustic Panel | EAP | ≤3000 | 600 | 50 |
≤3300 | 75 | |||
≤3600 | 100 | |||
≤4200 | 120 | |||
≤5200 | 150 | |||
≤6000 | 200 | |||
≤6000 | 250 | |||
≤6000 | 300 | |||
Note: Other special sizes of panels and blocks can be ordered as per clients’ requirements.
Advantage of Eastland AAC Panels
Key Benefits of using Eastland AAC Acoustic Panel in your next project include:
Outstanding Sound Insulation Performance
Customized dense closed-cell structure specially optimized for noise blocking, effectively blocks airborne noise between rooms, factory & highway noise transmission, perfect for party wall, studio and noise barrier engineering.
Superior Fire Resistance Safety
Fully non-combustible inorganic AAC material, no toxic fume while burning, complies with Australian standard, prevents fire spread for commercial & residential construction.
Energy-saving Thermal Insulation
Low thermal conductivity cellular structure delivers stable thermal performance, cuts long-term electricity cost for buildings.
Lightweight & Fast Dry Construction
Only 1/5 weight of solid concrete, big-size precast panel shortens wall erection time by 50% vs brickwork, less labour cost, dry installation without wet mortar on-site.
Eco-friendly Non-toxic Material
Zero formaldehyde & harmful volatile substance, made of natural sand, lime & cement, green building material matching Australia sustainable constructioequirement.
Packing & Shipping
Standard pallet packing with plastic film and steel strapping
Waterproof, shockproof, suitable for long-distance ocean shipping
Custom packing acceptable
Strict quality inspection before delivery
